Electrical Specifications |
|
|
频率 |
698-960 or 1710-2100 or 2500-2700 MHz |
|
增益 |
8 dBi |
|
Horizontal Beam Width |
90 deg |
|
Vertical Beam Width |
55 deg |
|
驻波比 |
700-750MHz:VSWR<=2 750-2500MHz:VSWR<=2 |
|
阻抗 |
50 ohm |
|
最大功率 |
100 W |
|
Front to back radio |
>=15 dB |
|
Mechanical Specifications |
|
|
连接头类型 |
Custom |
|
Dimensions of Antenna |
Custom |
|
重量 |
0.5 kg |
|
温度 |
-40-60 |
